H360
LED Moving Head
- 360W CW LED
- 25500Lux @ 10m
- Compact fixture with high efficient optical system
- Color wheel, dual gobo wheel
- Bi-directional 8/24-facet prism with variable speed
- Best for concert, bar, events, road show etc.
- DMX control
360W CW LED
LIGHT SOURCE
13500Lm
LUMENS
7200K±300K
COLOR TEMPERATURE
3.4°- 37.7°
BEAM ANGLE
22KG
WEIGHT
355 x 257x 643 mm
DIMENSION
Ultra-efficient optical system
- 360W CW LED
- 25500Lux @ 10m
- Compact fixture with high efficient optical system
- Color wheel, dual gobo wheel
- Bi-directional 8/24-facet prism with variable speed
- Best for concert, bar, events, road show etc.
- DMX control
TECHNICAL SPECS
PHOTOMETRICS
- Light Source
360W CW LED
- Output narrow angle
narrow angle：5050Lm，wide angle：13500Lm
- LUX
102000Lux@5m；6500Lux@3m
- Color Temperature
7200K±300K
- Lifespan
20000hrs
- Beam Angle
3.4°~37.7°
KEY FEATURES
- Pan
540°(16 bit)
- Tilt
270°(16 bit)
- Color System
CW + 9 filters + open
- Gobo System
7 rotating gobos+open , 12 fixed gobos+open
- Focus
Motorzed linear focus
- Frost
5° forst
- Strobe
0~30Hz
- Dimming
4 dimming curves，0～100% dimming
- Prism
Bi-directional 8/24-facet prism with variable speed
- Slogan Template
Slogan Template
- Framing System
Single blade ±35°, rotatable 180°
- Iris
NA
- Frost
Frost glass
- Prism
Bi-directional, combinable, 8-facet + 4-facet prism
CONTROL
- Protocol
DMX512/RDM
- DMX Channels
21CH
- Onboard Menu
2.0 inchesTFT display
- Slogan Template
Slogan Template
- Slogan Template
Slogan Template
- Slogan Template
Slogan Template
- Slogan Template
Slogan Template
POWER
- Mains
200～240VAC,50～60Hz
- Power Connections
PowerCon In/Out
- Data Connections
3pin DMX In/Out, Maximum with 32pcs
- Consumption
420W@230V；400W@230V
- Power Factor
0.98/230V
- Ambient
0℃~45℃
- Slogan Template
Slogan Template
- Slogan Template
-20°C – 45°C
PHYSICAL
- Dimension
355 x 257x 643 mm
- Weight
22kg
- Cooling
Heat pipe and low noise fan
- Slogan Template
Slogan Template
- Slogan Template
Slogan Template
PRODUCT EFFECTS
ACCESSORIES
- Slogan Template
Omega bracket, power cable
